The conveyor is designed for unloading without the need of electrical power supply or a specialized expensive loading bay or dock and will extend up to 10 Meters inside a trailer or shipping container.
This heavy duty telescopic gravity conveyor is mounted on a heavy duty steel box section chassis and is adjustable in height to reach common trailer and container floor heights.
Standard Width is 600mm Fitted with 50mm diameter low inertia PVC rollers at 65mm centres it is will handling small and large parcels alike. Smooth transfer between decks is achieved by a series of 20mm diameter steel rollers. Other widths are available to special order.
Working height is adjusted by manually operated screw jacks to set the correct gravity fall.
To bring height down further we recommend that it be used in conjunction with our High Level Gravity Roller Extension Track or other conveyors from our extensive range to reach comfortable working heights and further into warehouse or production areas
This is now supplied as standard with the Container Unloading Conveyor
Gravity roller conveyor 3 Metre long x 600mm track width of fully welded construction mounted on a robust chassis with 5″ diameter castors and screw jack height adjustment. Fitted with 50mm diameter PVC rollers at 75mm centres, connecting hooks to join to high level telescopic gravity unloading conveyor and fixed end stop.
Please email for advice on models, full details and quotations.
